Revolving Motor / Needle Winding Machine 1200rpm Brushless Dc New Energy

Name: Revolving Motor Needle Winding Machine 1200rpm Brushless Dc New Energy
Brand: WIND AUTOMATION
Price: 1 USD

Revolving Motor / Needle Winding Machine 1200rpm Brushless Dc New Energy Manufactures

Brand Name : WIND AUTOMATION

Model Number : WIND-T1000

Certification : CE

Place of Origin : China

MOQ : 1PC

Price : Negotiable

Payment Terms : T/T

Delivery Time : 30 Working days

Condition : New

Certificate : CE

Working Station : Two or Four

Wire Size : Thin Wire from 0.01mm

Automatic Type : Fully Automatic can handle thin wire thick wire

Machine Color : White or Per Customer Requirement

Winding Speed : 1000 ~ 1200RPM

After sales : Engineers available to service machinery overseas

Contact Now

1200RPM Brushless DC New Energy Revolving Motor Stator Needle Winding Machine WIND-T1000

(1) Application

High Efficiency Needle winding for BLDC Stators

Small Pump Motor, New Energy Automobile Car Revolving Motor,

DC Brushless Motor,New Energy Car Spinning Stator Winding Machine

(2) Advantages

Dedicated Winder for small motor with thin wire, crazy fast 1000~1200RPM,

Four station BLDC Stator winding machine WIND-T1000 wind the brushless DC motor stator

with four station to improve efficiency!

(3) Parameter

Wire diameter:0.01 to 0.70 mm (suitable for thin wire and small stator)

Stator ID: 12 to 130 mm

Stack height: 5 to 30mm

Winding motor: Servo motor Panasonic 3000W 1pc

Arraying motor: Servo motor Panasonic 2000W 2pcs

Indexing motor; Servo motor Panasonic 750W 2pcs

Speed: 300 to 600 RPM

Air pressure:5~7kg/square centi-meter

Power:AC380V 50/60Hz

Weight: about 480kgs

Dimension: 1800(L)x850(W)x1600(H)mm

Below samples are needed for machine manufacturing and commissioning:

1. Stator stack 5pcs without winding

2. Wound stator 1pc

3. Copper wire 1 roll enough for winding 15pcs stators

Revolving Motor / Needle Winding Machine 1200rpm Brushless Dc New Energy

Please click below video to watch machine winding for 14 pole new energy vehicle rotary motor

https://youtu.be/W88vS8VnByA
